Bryston Bi-200 Integrated Amplifier

The Clever Amp!
Bryston integrated amplifiers give no ground to their separate counterparts. The new Bi-200 is literally constructed from the Bryston BP-19 Preamplifier and 3B amplifier into a single chassis offering the best of both products without occupying extra space and costly interconnects.
High performance and transparency is always Bryston's goal and an integrated amplifier doesn’t have to compromise ability for con- venience. Build your ultimate dream system with our separates or keep your stereo compact and discrete with our Bi-200 Inte- grated Amplifier.
BRYSTON Bi-200 ANALOG CIRCUITS
The Bi-200 analog integrated amplifier is a byproduct of years of R&D that resulted in the development of an optimized discrete buffer amplifier capable of delivering a staggeringly low THD+N distortion.
A PATH TO GREATNESS
The analog signal path is a fully balanced design, using an array of very tightly matched components and a compact circuit de- sign to achieve the lowest possible noise and superior common mode rejection. With the new balanced inputs and outputs we have been able to make significant improvements in perfor- mance in the Bi-200.
In the past, a fully balanced signal path was difficult to achieve because you would need a volume pot with 4 tapers, now, with the availability of these new volume control chips, this is no longer an issue.
This new design allows for a lower noise floor than previous de- signs and is much better at common mode noise suppression. For the music enthusiast, this level of circuit sophistication means more life-like performances, more detail and more dimen- sionality from the recordings you love.
Product Features
- Full Balanced Discrete Circuit Path
- Analog Volume ... Digitally Controlled
- Connect up to 6 analog sources
- Optional low distortion MM/MC Phono module
- Dual-mono amplifier produces 200 watts into 8 ohms
- 300 watts per channel into 4 ohms.
- Channel balance control
- Fully convection cooled means no noisy fans
- Independent buffered headphone output
- Machined aluminum enclosure and dress panel
- 2-way RS232 for automation systems
- Compatible with BR-4 remote control
- Soft-Start microprocessor won't trip circuit breakers
- DC trigger out
- Legendary Bryston 20 Year Warranty on Analog
- Ethernet/USB/RS232 status control
Technical Specifications
Frequency Response
20Hz - 20kHz: ± 0.05dB
Signal To Noise
Weighted Filter: 22Hz-22kHz, decibels below rated output
IMD
≤0.0005%
THD+N
20Hz-20kHz @ 200W, 8Ω
Power Consumption (120V/60Hz)
Standby
Faceplate Finishes
Black
Silver
Faceplate Sizes
17" (43.18 cm)
19" (48.26 cm)
Dimensions (W x H x D)
43 or 48.3 x 11.6 x 33
