Sumiko Palo Santos Presentation Low Output MC Cartridge
- Availability:
- Usually Ships in 48 - 72 Hours
- Shipping:
- Free Shipping
Description
Meet the Sumiko Palo Santos Presentation
Low Output MC Cartridge
For over thirty-five years, SUMIKO has provided a comprehensive range of phono cartridges to music lovers seeking the finest musical experience at a variety of price points. In fact, the great market success of SUMIKO phono cartridges has hinged on their phenomenal cost-to-performance ratio.
The Palo Santos Presentation is no exception. New design requirements incorporating advances in material technology and construction techniques have resulted in a significantly improved product which delivers a highly refined and resolved, yet musically satisfying sound quality previously unavailable at or even near its price.
Improvements grace virtually every facet of the product to differentiate it from its smaller sibling the Pearwood Celebration II. Most significant is the new generator anchoring system, which has substantially improved rigidity and reduced resonance and background noise to previously unheard of levels.
From the new handcrafted Palo Santos (Brazilian Rosewood) body, which is shorter in height to add vision when mounting and aligning this cartridge, to the Long Grain Boron cantilever and new Line Contact stylus, which significantly improves resolution, the Palo Santos Presentation truly deserves the title as our flagship offering.
HAND CRAFTED IN JAPAN
Each Sumiko phono cartridge is hand assembled by the world-class cartridge makers at Excel Sound in Yokohama, Japan, a relationship they’ve proudly maintained for nearly forty years, using only the finest materials that combine to deliver performance that has enlightened generations of listeners.
Each design is thoroughly auditioned until it meets Sumiko's stringent standards for sound. Production is then executed by expert craftsmen with a collective eye for precision and quality.
The result is a family of premium cartridges that render emotion through tonally balanced, refined and fatigueless analog reproduction.
TECHNICAL SPECIFICATIONS
Mass & Dimension (W x H x D)
6g, 17.37 x 17.16 x 23.94 mm
Stylus
0.3 x 0.7mil Elliptical
Cantilever
Aluminium Pipe
Coils
High-Purity Copper
Internal Impedance
28Ω
Load Impedance
<100kΩ
Frequency Response
13Hz – 35kHz
Output Voltage
0.5mV @ 1kHz
Channel Separation
30dB @ 1kHz
Channel Balance
<1dB @ 1kHz
Compliance
12 × 10-6cm/dyn @ 100Hz
Capacitance
100pF – 200pF
Vertical Tracking Angle
20°
Tracking Force Range
1.8g – 2.2g
Recommended Tracking Force
2.0g
*This information has been obtained from Manufacturers website. We advise that Price, Features & Specifications are subject change without notice.
E&OE
