Introducing the Masterclass IA-4 Remote Volume Integrated Amplifier
Pure Class ‘A’ Integrated Stereo Amplifier – 33 watts
The Sugden Masterclass IA-4 Pure Class ‘A’ Integrated Amplifier is the largest and most powerful integrated amplifier in the Sugden family which takes advantage of the initial Sugden Class ‘A’ output configuration.The Pure Class ‘A’ solid state output stage equipped with greater power from a custom-built transformer and low impedance supply can project and fill an enormous holographic sound stage.
An extraordinary, organic, euphonic, acoustic performance, achieved by the integration of a state of the art preamplifier and the classic Sugden Class ‘A’ output stage.The integrated system of pre-amplifier and power amplifier driven by individual power supplies enables the ultimate in musical performance.
Just listen – you will find it worth more than a thousand words.Despite the high power installed, Sugden have included a Moving magnet phono stage of extremely high quality.
Individually hand-made in England.
Product Features & Specifications
Inputs
Three line level
One tape
One Moving Magnet phono
One balanced
Outputs
Variable pre-out
Fixed out
Loudspeaker out
Volume Control
Remote control RC5 compatible
Tape
Monitor and record off
Input Sensitivity
125mV for maximum output
Phono Input Sensitivity
2mV Moving Magnet
Power Output
33 watts into 8 ohms both channels working
Frequency Response
14Hz to 200kHz +/-1dB
Bandwidth
6Hz to 300kHz +/- 3dB
Signal to Noise
>84dB
Overall Dimensions (H x W x D) including terminals
165mm x 430mm x 440mm (HWD)
*This information has been obtained from Manufacturers website. We advise that Features & Specifications are subject change without notice.
E & O E
